General Details
GAI Labellers – 9000 Series
EXTERIOR BOTTLE WASHING, DRYING, SPARKLING CAPSULE DISPENSING, PLEATING, CRIMPING, HEAT SHRINK, SPINNING HEADS AND SELF-ADHESIVE LINEAR LABELLING
The GAI 9000 linear series labellers are the ultimate for sparkling finished bottle packaging. Offering a full range of capabilities for the customers individual packaging requirements. The GAI 9000 series monoblocks are designed for bottle washing, drying, sparking capsule dispensing, pleating, crimping, heat shrink, spinning heads and self-adhesive labelling.
The 9000 series has been designed to work from 800 to 4,000 bottles per hour.
Technical Info
| FUNCTION | 9213 | 9313 | 9323 | 9343 | |
| Washing + drying station | n | 1+1 | 1+1 | 1+1 | 1+1 |
| Head Dispenser | n | 1 | 1 | 1 | 1 |
| Shrinking heads | n | 1 opt. | 1 opt. | 2 opt. | 1 opt. |
| Shrinking speed | b/h | 800-1600 | 800-2400 | 1000-2000 | 1000-2400 |
| Sleeking heads | n | 1 | 1 | 2 | 4 |
| Sleeking speed | b/h | 800-1200 | 800-1200 | 1000-2000 | 1000-2400 |
| Labelling station max | n | 3 (4 opt.) | 3 (4 opt.) | 3 (4 opt.) | 3 (4 opt.) |
| Labeller plates | n | – | – | – | – |
| FUNCTION | 9443 | 9643 | 9400-4 | 9400-6 | |
| Washing + drying station | n | 1+1 | 1+1 | 1+1 | 1+1 |
| Head Dispenser | n | 1 | 1 | 1 | 1 |
| Shrinking heads | n | 1 opt. | 1 opt. | 1 | 1 |
| Shrinking speed | b/h | 1000-2500 | 1000-2500 | 1000-3000 | 1000-2400 |
| Sleeking heads | n | 1 | 1 | 2 | 4 |
| Sleeking speed | b/h | 800-1200 | 800-1200 | 1000-2000 | 1500-4000 |
| Labelling station max | n | 3 (4 opt.) | 3 (4 opt.) | 3 | 3 |
| Labeller plates | n | – | – | 4 | 6 |
*Not binding data.
