Mak Rotary Cold Glue Labeler – Up to 4 Removable Modules
Cold Glue – Mak Rotary up to 4 Removable Modules
Medium to large labelling machines for high production speeds, integrable with multiple applications and the non-stop system.
Large carousel size allows the labelling machine to achieve particularly high production speeds (up to 50,000 b/h).
Large size ensures that the operator works in perfect comfort, safety and practicality, facilitating machine cleaning operations.
All the cold glue labelling units in the range (MAK-GS MAK-G, MAK-GH and MAK-GLL) ensure high productive efficiency while permitting rapid dismantling of tools for maintenance, making this task simple and intuitive for the operator.
They are controlled entirely through touch panels, with intuitive control to optimize production and obtain outstanding results.
There is plenty of space for addition of an automatic magazine on the labelling unit to permit non-stop production.
The MAK Rotary permits integration of a number of different options, ranging from conveyance to centring systems such as Raptor and Follower and control systems such as Alice.
- High performing
- Modular
- Flexible
Description
Machines
| Model | Speedb/h | Machine ⌀ mm |
Platform | Stations |
|---|---|---|---|---|
| MAK-4 | 9.000 – 40.000 | 1350 | 10 up to 34 | 1 up to 4 |
| MAK-5 | 9.000 – 40.000 | 1560 | 12 up to 40 | 1 up to 4 |
| MAK-6 | 9.000 – 24.000 | 1800 | 20 up to 32 | 1 up to 4 |
| MAK-7 | 9.000 – 26.000 | 2160 | 24 up to 40 | 1 up to 4 |
| MAK-8 | 9.000 – 26.000 | 2340 | 24 up to 54 | 1 up to 4 |
Labelling units
| Station | Division | Model |
|---|---|---|
| MAK-GS | 2/2 – 3/3 | MAK-4/5/6 |
| MAK-G | 2/3 – 3/3 – 4/4 – 4/5 – 5/5 – 5/6 – 6/6 | MAK-4/5/6/7/8 |
| MAK-GHS | 4/4 – 5/5 – 6/7 – 8/8 – 8/9 | MAK-4/5/6/7/8 |
| MAK-GLL | 4/4 – 5/4 | MAK-4/5/6/7/8 |
- Modular rotary labelling machines for high production speeds
- High-speed labelling stations, MAK-HS2 model
- Fast interchangeability between different technology modules
- Ease of maintenance and format changeover
